Image is representational - see mfr. specs

AHDP06-24-21SR-SRA

The AHDP06-24-21SR-SRA is a 21-position, shell size 24 circular plug from the DuraMate AHDP series, featuring a thermoplastic body, socket contacts, and a smooth ring adapter for compact installations. ...

Datasheet

RoHS Compliant

Box Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The AHDP06-24-21SR-SRA is a heavy-duty, environmentally-sealed circular plug connector designed for reliable performance in harsh off-road applications. It features a shell size 24 thermoplastic housing with a 21-position insert arrangement, accommodating four size 12 socket contacts rated for 25A and seventeen size 16 socket contacts rated for 13A. This connector provides a superior IP68/IP69K environmental rating when mated and operates across a temperature range of -55°C to +125°C. The integrated Smooth Ring Adapter (SRA) allows for a smaller footprint without requiring a backshell, making it ideal for use in heavy-duty transportation, agricultural, and industrial equipment where space and durability are critical.

Product Highlights:

Potential Applications:

Search Keywords: AHDP062421SRSRA

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol Sine Systems

Part No:

AHDP06-24-21SR-SRA

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538908180

COO:

ECCN:

EAR99
