AT04-12PA-P026

Name: AT04-12PA-P026
Brand: Amphenol Sine Systems
SKU: 50775159
Price: 31.8 USD
Availability: InStock

The AT04-12PA-P026 is a 12-position, Keyed A, HYPERBUSS™ AT Series bussed receptacle connector designed for creating common electrical pathways in heavy-duty applications. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

BOX Packaging

Certificate of Compliance

DESCRIPTION

The AT04-12PA-P026 is a 12-position bussed receptacle from the HYPERBUSS™ AT Series, used to create a common electrical junction for power distribution. This connector features a grey thermoplastic housing in a Keyed A configuration and is internally arranged as two separate 6-pin busses, with each buss rated for a maximum of 39A. It is equipped with size 16 nickel-plated copper alloy contacts and is designed to operate reliably in a temperature range of -55°C to +125°C. When mated with a corresponding AT06 series plug, it provides an IP67-rated seal for superior environmental protection. This robust connector is ideal for use as a splice or tap block in demanding industries such as transportation, marine, military, and agriculture.

Product Highlights:

Potential Applications:

Search Keywords: AT0412PAP026

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol Sine Systems

Part No:

AT04-12PA-P026

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536698000

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
