AT06-3S-RD01BLK

Name: AT06-3S-RD01BLK
Brand: Amphenol Sine Systems
SKU: 49187137
Price: 48.64 USD
Availability: InStock

3-Way Plug, Black Female Connector with Reduced Diameter Seal (E-Seal) ...

View Datasheet Ask the Datasheet

RoHS Compliant

EACH Packaging

Certificate of Compliance

DESCRIPTION

AT06-3S-RD01BLK is a 3-position thermoplastic plug connector from the Amphenol AT Series designed for heavy-duty industrial applications. This connector features IP68 and IP69K environmental protection ratings when mated, with a thermoplastic UL94-V0 rated housing and silicone rubber sealing material. It supports a maximum current of 13A (Size 16) and maximum voltage of 250V, with an operating temperature range of -55°C to +125°C. The connector incorporates an integrated latch coupling system and offers excellent resistance to gas, oil, mineral oil, acid bath, and basic bath fluids. Common applications include industrial equipment, automotive, and harsh environment installations where reliable electrical connections and superior environmental sealing are required.

Product Highlights:

Potential Applications:

Search Keywords: AT063SRD01BLK

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol Sine Systems

Part No:

AT06-3S-RD01BLK

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538908180

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
