ATP06-2S-KIT01

Name: ATP06-2S-KIT01
Brand: Amphenol Sine Systems
SKU: 49185842
Price: 69.97 USD
Availability: InStock

2-Way Socket Plug, Wedge and Contacts Kit ...

View Datasheet Ask the Datasheet

RoHS Compliant

BAG Packaging

Certificate of Compliance

DESCRIPTION

ATP06-2S-KIT01 is a 2-position plug kit from the Amphenol Sine Systems ATP Series™ designed for heavy-duty industrial applications requiring reliable multi-pin connectivity. The kit includes one plug connector, two socket contacts (Size 12), and one AWP-25 wedgelock, all rated for 25A continuous current at 250V. The connector features a thermoplastic housing with superior UV resistance, excellent dielectric and mechanical properties, and is RoHS compliant. The integral latching system ensures definitive electrical and mechanical connections with environmental seals providing IP68/IP69K protection. Performance specifications include insulation resistance of 1000 megohms minimum at 25°C, contact retention of 70 lbs for Size 12 contacts, and thermal cycling capability with no cracking or leaking after 20 cycles from -55°C to +125°C. This kit is ideal for industrial equipment, machinery, and systems requiring robust, sealed connectors that maintain continuity under vibration (21 G's at 10-2000 Hz) and physical shock (50 G's in three perpendicular planes).

Product Highlights:

Potential Applications:

Search Keywords: ATP062SKIT01

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol Sine Systems

Part No:

ATP06-2S-KIT01

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536698000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
