P5916G4-BK
Anderson Power ProductsConn Housing RCP ST Cable Mount ...
DESCRIPTION
P5916G4-BK is a black Powerpole PP75 standard connector housing designed for high-current power distribution applications. This housing is the second smallest in the Powerpole series and accommodates wire contacts up to 6 AWG (10 mm²) as well as PCB and busbar contacts, with a maximum current rating of 120 amps for wire-to-wire connections. The connector supports wire sizes ranging from #16 AWG (1.3 mm²) to #6 AWG (13.3 mm²) using reducing bushings, and features a voltage rating of 600V AC/DC per UL 1977. The housing is constructed from standard resin material and is suitable for wire-to-wire, wire-to-board, and wire-to-busbar applications, making it ideal for automotive, industrial power systems, and renewable energy installations where reliable high-current connections are essential.
Search Keywords: P5916G4BK
SPECIFICATIONS
IN STOCK: 788
Ships today, if you order in
MOQ for In Stock Qty: 25
MOQ for out of Stock Qty: 250
Factory Lead-Time 6 Weeks
Price (USD)
Tools/3D Models
Product Guides
Datasheet
