12146A by apem inc.
Image is representational - see mfr. specs

12146A

APEM Inc.

Switch Toggle ON ON DPDT Round Lever Solder Lug 4A 250VAC 30VDC Panel Mount with Threads ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 12146A is a professional double-pole toggle switch from the 12000 series, featuring a 26° angle of throw and solder lug terminals designed for robust panel-mounted applications. It incorporates a threaded bushing with Ø 11.9 mm (15/32-32UNS) and is available with multiple contact material options including silver (A), silver with gold plating (AD2), or solid gold rivet (D) contacts. The switch supports a maximum current/voltage rating of 4 A at 30 VDC with silver contacts, an initial contact resistance of 10 mO maximum, and insulation resistance of 1,000 MO minimum at 500 VDC. It features a contact bounce of 2 ms maximum and is CECC approved, conforming to ML specifications for high-specification environments. The switch is suitable for applications requiring reliable toggle action with smooth mechanical operation and offers optional front panel sealing, locking levers, and various actuator configurations for enhanced functionality and environmental protection.

Search Keywords: 12146A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
APEM Inc.
Part No:
12146A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
FR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
4@125VAC 30VDC A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
18.2 x 18.2 x 46.9 mm
Operating Temperature:
-40 to 85 °C

IN STOCK: 24

Ships today, if you order in

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$41.01
5
$37.63
10
$36.83
25
$35.30
50
$35.11
100
$34.14
250 +
$33.97
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

U53

Switch Access Knurled Nut

U1634

U124

U123

Knurled Cap Nut - 15/32-32.

U13

Switch Access Lockwasher

Show 3 More
