12166A by apem inc.
Image is representational - see mfr. specs

12166A

APEM Inc.

Switch Toggle ON ON 4PDT Round Lever Solder Lug 4A 250VAC 30VDC Panel Mount with Threads ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 12166A is a four-pole professional toggle switch from the 12000 series, designed for high-specification environments requiring robust switching performance. It features solder lug terminals with a 26° angle of throw and ON-OFF-ON switching function across all four poles, with a threaded bushing of Ø 11.9 mm (15/32-32UNS) for secure panel mounting. The switch is CECC approved and conforms to military specifications, offering smooth mechanical toggle action and multiple front panel sealing options for protection against dust and water. Key electrical characteristics include a maximum current rating of 4 A at 30 VDC with silver contacts, initial contact resistance of 10 mO maximum, and insulation resistance of 1,000 MO minimum at 500 VDC. The 12166A is ideal for aerospace, defense, industrial control, and other demanding applications where reliability and precise switching control are essential.

Search Keywords: 12166A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
APEM Inc.
Part No:
12166A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
FR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Pole Throw Configuration:
4PDT
Switch Configuration:
On On
Contact Rating @ Voltage:
4@125VAC 30VDC A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
18.2mm x 26mm x 46.9 mm
Operating Temperature:
-40 to 85 °C

IN STOCK: 4

Ships today, if you order in

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$70.71
5
$67.97
10
$66.99
20
$65.19
60
$57.46
100 +
$52.47
