3533001N000 by apem inc.
Image is representational - see mfr. specs

3533001N000

APEM Inc.

Switch Toggle OFF Mom SPST Round Lever Screw 15A 250VAC 28VDC Panel Mount with Threads ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3533001N000 is a high-performance toggle switch from the 3500 series, designed for environmentally sealed applications with complete protection against moisture and pressure ingress. It features front sealing to IP67 or IP69K via silicone membrane and rear sealing to IP64 through moulded-in terminal inserts, with a 22° throw angle and OFF-MOM function configuration. The switch is rated for 10,000 electrical cycles at 15 A 28 VDC resistive load, 15 A 28 VDC inductive load, and 5 A 28 VDC lamp load, with an initial contact resistance of 10 mO maximum at 1 A 2 VDC. Operating reliably across -40°C to +85°C with 56 days moisture resistance and approved to European standards CECC 96000, this switch is ideal for demanding industrial control, marine, and automotive applications where environmental sealing and electrical reliability are critical.

Search Keywords: 3533001N000

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
APEM Inc.
Part No:
3533001N000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
FR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Pole Throw Configuration:
1P1T (SPST)
Switch Configuration:
OFF None (ON)
Contact Rating @ Voltage:
15@28VDC A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
32 x 15 x 60.3 mm
Operating Temperature:
-40 to 85 °C

IN STOCK: 24

Can Ship immediately

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$43.30
5
$40.81
10
$40.19
25
$39.34
50
$35.40
100
$28.91
250 +
$28.37
