4646A22UU by apem inc.
Image is representational - see mfr. specs

4646A22UU

APEM Inc.

Switch Toggle ON ON DPDT Flat Lever Quick Conn/Solder Lug 6A 250VAC Panel Mount with Threads ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

4646A22UU is a double pole ON-ON toggle switch from the APEM 4600-4400 series, featuring an insulated flat lever actuator in black and silver contacts. It is equipped with solder lug/quick-connect terminals and offers a maximum current/voltage rating of 4 A at 250 VAC or 6 A at 125 VAC with resistive load. The switch features UL/CSA approval with rated specifications of 3 A 250 VAC or 6 A 125 VAC. Key specifications include an initial contact resistance of 10 mO max, insulation resistance of 1,000 MO min at 500 VDC, and an electrical life of 10,000 cycles at full load. The operating temperature range is -20°C to +55°C, and the switch mounts in a 12.00 mm diameter panel cutout. This toggle switch is ideal for panel-mounted control applications requiring reliable switching performance and agency approvals.

Search Keywords: 4646A22UU

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
APEM Inc.
Part No:
4646A22UU
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
FR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
6@125VAC A
Actuator Style:
Flat Lever
Mounting:
Panel Mount with Threads
Thread Size:
M12 x 0.75
Body Orientation:
Straight
Terminal Type:
Quick Connect/Solder
Dimension:
21 x 16.5 x 47.2 mm
Operating Temperature:
-20 to 55 °C

IN STOCK: 747

Can Ship immediately

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
20
$11.03
40
$10.94
60
$9.41
100
$8.72
260
$8.68
500
$8.66
1,000 +
$8.64
