641H/22V by apem inc.
Image is representational - see mfr. specs

641H/22V

APEM Inc.

Switch Toggle ON OFF DPST Locking Lever Quick Conn/Solder Lug 15A 400VAC 24VDC 372.85VA Panel Mount with Threads ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 641H/22V is a double-pole toggle switch from the 600H-600NH series designed for high-amperage panel-mount applications. It features a metal lever with screw terminals, a 26° angle of throw, and ON-OFF-ON electrical function configuration. The switch is constructed with a polyester UL94-V0 case, brass nickel-plated bushing, and silver/nickel alloy contacts, delivering robust performance with an initial contact resistance of 10 mO maximum and insulation resistance of 1,000 MO minimum at 500 VDC. It operates reliably across a temperature range of -20°C to +55°C and is approved to UL 1054, CSA 22-2, and EN 61058-1 standards. This switch is ideal for industrial control panels, machinery, and equipment requiring reliable high-current switching with durable mechanical construction.

Search Keywords: 641H22V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
APEM Inc.
Part No:
641H/22V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509050
COO:
FR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Pole Throw Configuration:
2P1T (DPST)
Switch Configuration:
OFF None ON
Contact Rating @ Voltage:
372.85 A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Quick Connect/Solder
Operating Temperature:
-20 to 55 °C

IN STOCK: 132

Ships today, if you order in

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$35.26
5
$34.02
10
$30.92
25
$30.07
50
$29.00
100
$28.03
250 +
$27.02
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
