8646AK by apem inc.
Image is representational - see mfr. specs

8646AK

APEM Inc.

Switch Push Button ON ON DPDT Round Plunger 6A 250VAC 30VDC Alternate Contact Solder Lug Panel Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 8646AK is a double-pole miniature pushbutton switch designed for momentary or alternate-action control applications in industrial and commercial equipment. It features silver contacts rated for 3 Amps at 250 VAC or 6 Amps at 125 VAC, with an initial contact resistance of 10 milliohms maximum and a dielectric strength of 2000 V rms minimum between terminals and 3000 V rms between terminals and frame. The switch operates across a temperature range of -20°C to +65°C with an electrical life of 10,000 cycles at full load and a total travel of 0.177 inches (4.5 mm). The housing is constructed from melamine-phenolic material with a polyamide actuator and bushing, and the switch is supplied with a hex nut and insulating knurled nut. This switch is commonly used in control panels, machinery, and industrial automation systems where reliable switching of moderate power loads is required.

Search Keywords: 8646AK

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
APEM Inc.
Part No:
8646AK
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509050
COO:
FR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Mounting:
Panel Mount
Pole Throw Configuration:
DPDT
Bushing Type:
Threaded
Switch Configuration:
On On
Contact Rating @ Voltage:
6A@125 VAC
Actuator Style:
Round Plunger
Illumination:
N/R
Terminal Type:
Solder
Body Orientation:
Straight
Dimension:
13.2 x 12 x 35.2 mm

IN STOCK: 30

Ships today, if you order in

MOQ for out of Stock Qty: 13

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
1
$45.38
5
$31.72
10
$31.40
13
$29.37
25
$28.45
38
$28.16
50 +
$27.01
Suppliers Standard Package
