AV091003C900 by apem inc.
Image is representational - see manufacturer specifications
APEM Inc. Authorized Distributor

AV091003C900

The AV091003C900 is a momentary (NO) security pushbutton switch with a 19 mm bushing, flat actuator, and screw terminals. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The AV091003C900 is a momentary (NO) security pushbutton switch from the AV series, featuring a flat actuator, short case, and nickel-plated brass construction. It is designed for panel mounting in a 19.2 mm cutout and has screw terminals for secure wire connections. The switch's silver-plated brass contacts are rated for 2A at 48 VDC with an electrical life of 10,000 cycles, while its mechanical life extends to 1,000,000 cycles. With a robust design and an operating temperature range of -30°C to +70°C, it is well-suited for industrial controls, security panels, and public-access equipment.

Search Keywords: AV091003C900

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
APEM Inc.
Part No:
AV091003C900
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
FR
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
20
Mounting:
Panel Mount
Pole Throw Configuration:
SPST
Bushing Type:
Threaded
Switch Configuration:
N.O.
Contact Rating @ Voltage:
2A@48 VDC
Actuator Style:
Flat Button
Illumination:
N/R
Terminal Type:
Screw
Body Orientation:
Straight

IN STOCK: 93

Can Ship immediately

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$49.14
5
$46.33
20
$40.26
40
$40.07
60
$38.81
100
$37.46
260 +
$37.37
