Image is representational - see mfr. specs

AV199035D200

APEM Inc.

Snap-Action Push Button Switch ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The AV199035D200 is an illuminated snap-action security pushbutton switch designed for secure access control and momentary switching applications. It features a 19 mm diameter housing with single pole NO (normally open) momentary action, gold-plated dome contacts, and gold-plated brass terminals for reliable electrical performance. The switch operates with an actuation force of 25 oz. ± 7 oz., a travel distance of 0.027" (0.7 mm) ± 0.003" (0.1 mm), and supports panel thicknesses from 0.039" (1 mm) to 0.433" (11 mm). It maintains a maximum initial contact resistance of 100 milliohms and an insulation resistance of 1000 megoohms minimum at 500 VDC, with an electrical life rating of 1,000,000 cycles at full load. The switch is ideal for security applications, industrial control panels, and access systems where durability and reliable momentary switching are essential.

Product Highlights:

Potential Applications:

Search Keywords: AV199035D200

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

APEM Inc.

Part No:

AV199035D200

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536509065

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
