HF33S11 by apem inc.
Image is representational - see manufacturer specifications
APEM Inc. Authorized Distributor

HF33S11

Joysticks 1 Direction 5000000Cycles ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The HF33S11 is a three-axis proportional multi-axis fingertip controller utilizing non-contacting Hall effect sensor technology for reliable, wear-free operation. It features analog ratiometric outputs with configurable voltage ranges (0-5V, 0.5-4.5V, 0.25-4.75V, or 1-4V), a supply voltage of 5 VDC ±0.01 VDC, and typical supply current of 40 mA (50 mA maximum). The device operates across a wide temperature range of -40°C to +85°C and provides IP67 sealing capability with output linearity of ±200 mV and dual output interlinearity specifications. The HF33S11 is well-suited for industrial control applications, mobile equipment, and machinery requiring proportional multi-axis input with robust environmental protection and precise analog feedback.

Search Keywords: HF33S11

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
APEM Inc.
Part No:
HF33S11
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8537109170
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Actuator Material:
N/A
Dimension:
48.26mm x 48.26mm x 100.86mm
Maximum AC Voltage Rating:
N/A
Maximum Current Rating:
N/A
Maximum DC Voltage Rating:
N/A
Mechanical Life:
5000000 Cycles
Number of Directions:
1
Number of Poles:
N/A
Operating Temperature:
-40 to 85 °C
Potentiometer Resistance:
N/A
Terminal Type:
N/A
Type:
N/A

IN STOCK: 7

Ships today, if you order in

MOQ for out of Stock Qty: 2

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$208.85
2
$208.33
3
$207.81
4
$207.29
5 +
$203.15
