MAB104G01C06B01A by apem inc.
Image is representational - see mfr. specs

MAB104G01C06B01A

APEM Inc.

Switch Snap Action N.O./N.C. SPDT Short Roller Lever 16A 250VAC 3.72N Screw Mount Quick Connect ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

MAB104G01C06B01A is a micro switch featuring a leaf spring contact mechanism and hinge lever actuator, designed according to DIN 41635 specifications. The switch incorporates a solid construction with high-quality materials and precise switching characteristics, with switching speed largely independent of actuation speed. It is equipped with a medium-length hinge lever (approximately 35.6 mm ±0.8 mm) and operates over an ambient temperature range of -10°C to +105°C. The device undergoes 100% functional final inspection and is certified to ISO 9001:2000 standards, ensuring reliable operation. Common applications include end-of-travel switches, industrial control systems, and appliance automation where dependable switching performance is required.

Search Keywords: MAB104G01C06B01A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
APEM Inc.
Part No:
MAB104G01C06B01A
Alias/AKA:
MAC6C
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Mounting:
Screw Mount
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
N/A/N/A/Phenolic/Short Roller Lever
Contact Rating @ Voltage:
16@250VAC@(ENEC/VDE) A
Maximum Movement Differential:
0.4 mm
Operating Force:
3.72 N
Termination Style:
Quick Connect
Dimension:
39.7mm x 10.3mm x 29.6 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 707

Can Ship immediately

MOQ for In Stock Qty: 10

MOQ for out of Stock Qty: 625

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
10
$7.85
100
$7.83
250
$7.81
625
$7.79
1,250
$4.11
1,875
$2.82
2,500 +
$2.77
Log in for special pricing Click for Quote Price Match Request
