PT65312 by apem inc.
Image is representational - see mfr. specs

PT65312

APEM Inc.

Switch DIP N.O./N.C. SP4T 4 Spindle 0.15A 24VDC 1.5VA PC Pins 10000Cycles 2.54mm Thru-Hole ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

PT65312 is a 4-position rotary DIP switch from the PT65 series featuring a spindle actuator and binary coded decimal (Code 12) encoding. The switch incorporates a 3 + 3 terminal layout with gold over nickel plated bronze contacts and terminals, completely sealed for process compatibility. It operates at a maximum voltage of 24 VDC with a static contact rating of 400 mA and dynamic contact rating of 150 mA, delivering a switching capacity of 1.5 VA maximum. The device features precision-designed detent action with a minimum torque of 7.0 inch-oz (0.7 Ncm), an expected life of 10,000 switching operations, and operates reliably across a temperature range of -20°C to 70°C. PT65312 is ideal for industrial control systems, equipment configuration, and applications requiring compact, sealed rotary switching with extensive coding options.

Search Keywords: PT65312

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
APEM Inc.
Part No:
PT65312
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Body Orientation:
Straight
Actuator Style:
Spindle
Actuator Length:
7.3 mm
Number of Positions:
4
Pole Throw Configuration:
SP4T
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
1.5 A
Contact Plating:
Gold/Nickel
Terminal Pitch:
2.54 mm

IN STOCK: 351

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 28 Weeks

Price (USD)

Qty
Unit Price
1
$7.602
5
$6.911
25
$6.685
50
$6.592
100
$5.562
250
$5.449
500
$4.934
1,000 +
$4.481
Suppliers Standard Package
