Image is representational - see mfr. specs

Q12P1CXXG12E

APEM Inc.

LED Panel Mount Indicator Uni-Color Green 50mcd Automotive 2-Pin ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

Q12P1CXXG12E is a 12mm panel mount LED indicator featuring a prominent bezel style with solder lug/faston (2.8 x 0.8) terminals and bright chrome plated brass bezel finish. The indicator operates at 12VDC with an operating voltage range of 10.8 to 13.2VDC and a typical operating current of 20mA, with a maximum reverse voltage of 5V. It includes an 8mm colored diffused epoxy lens or water clear super bright LED, IP67 sealing per EN60529, and is supplied with a fixing nut and spring washer. The device is rated for a life expectancy of 100,000 hours and operates reliably across a temperature range of -40°C to +85°C. This LED indicator is ideal for panel-mounted status indication in industrial control panels, instrumentation, and equipment requiring reliable visual feedback with environmental protection.

Product Highlights:

Potential Applications:

Search Keywords: Q12P1CXXG12E

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

APEM Inc.

Part No:

Q12P1CXXG12E

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8539520091

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
