DESCRIPTION

ST1-1F2MV1BE is a miniature single-pole toggle switch featuring a flatted actuator and vertical right-angle PC-mounted terminals designed for panel mounting applications. The switch offers dry circuit through power ratings with ultra-rugged construction, supporting contact ratings of 6 Amps at 125 VAC, 3 Amps at 250 VAC, or 7 Amps at 30 VDC for power models. Key electrical characteristics include an initial contact resistance of 3 milliohms maximum at 3 VDC with 0.1 Amp, insulation resistance greater than 200,000 megohms between terminals and case ground, and dielectric strength exceeding 2000 VAC for 1 minute. The switch is rated for a minimum of 100,000 electrical cycles under resistive loads and is available with various terminal configurations and mounting options, making it suitable for industrial control panels, instrumentation, and consumer electronics requiring reliable switching performance.
