10762802
2.8 Clean Body APEX Female SN Unsealed Terminal ...
DESCRIPTION
The 10762802 is an APEX® 2.8 series unsealed female terminal designed for high-current power distribution in automotive and industrial applications. It features two-piece construction with an integrated floating spring made of beryllium copper or copper nickel silicon, supporting wire sizes from 12 to 10 AWG (4.0 to 6.0 mm²) with tin (Sn) plating and optional gold (Au) plating. The terminal delivers a contact resistance below 2 mO, a contact mating force below 5 N, and an unmating force below 2 N, ensuring reliable low-force connections. With a tangless/lanceless locking mechanism and APEX® cavity design, it is compatible with APEX® 2.8 unsealed and sealed series housings as well as mixed and ErgoMate™ series housings. This terminal is ideal for heavy-duty applications requiring highest current ratings and low contact resistance in sealed or unsealed connector assemblies.
Search Keywords: 10762802
SPECIFICATIONS
IN STOCK: 24,000
Can Ship immediately
Minimum Order Quantity: 2000
Multiple: 2000
Factory Lead-Time 10 Weeks
Product Drawing
Datasheet
