LCC600-48U-9P by artesyn / advanced energy
Image is representational - see manufacturer specifications
Artesyn / Advanced Energy Authorized Distributor

LCC600-48U-9P

The LCC600-48U-9P is a fully enclosed, conduction-cooled 600W AC-DC power supply that provides a primary 48V output. ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The LCC600-48U-9P is a single-output, conduction-cooled AC-DC power supply from the Artesyn LCC600 series, designed to deliver 600 watts of continuous power. It operates from a universal AC input range of 90 to 264 Vac and provides a nominal 48 Vdc main output, which is adjustable from 44 V to 54 V. This model can supply a maximum current of 12.5 amps and operates with a typical efficiency of 93.0%. A secondary 5 Vdc standby output is also available, capable of supplying up to 1.5 amps. Designed for fanless operation, it features a thermal baseplate for effective heat dissipation over a wide operating temperature range of -40°C to 85°C, making it suitable for demanding industrial and medical applications.

Search Keywords: LCC60048U9P

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Artesyn / Advanced Energy
Part No:
LCC600-48U-9P
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504409540
COO:
PH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
24
Package Type:
OTHER

IN STOCK: 2

Ships today, if you order in

On Order: 24   can ship 3/8/27

MOQ for out of Stock Qty: 6

Factory Lead-Time 27 Weeks

Price (USD)

Qty
Unit Price
1
$856.80
6
$854.65
12
$451.07
18
$310.21
24 +
$304.00
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
