NPS44-M by artesyn / advanced energy
Image is representational - see manufacturer specifications
Artesyn / Advanced Energy Authorized Distributor

NPS44-M

AC-DC Power Supply - Open Frame - Medical - 15VDC - 3A - Input: 90 to 264VAC - 4 x 2 x 1 inches ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The NPS44-M is a 40 W open-frame AC-DC power supply from Artesyn's NPS40-M series, delivering a fixed 15 V output with single output configuration. It features universal input voltage (90 to 264 VAC or 127 to 300 VDC), typical full-load efficiency of 87%, and no-load power consumption less than 300 mW. The unit provides a maximum load of 3 A with convection cooling and 4 A with 200 LFM forced air, with output regulation of ±2% and ripple of 150 mV peak-to-peak. The NPS44-M includes medical and ITE safety approvals (UL 60950-1, UL 60601-1, IEC 62368-1), dual AC fuses, remote sense capability with 0.5 V lead drop compensation, and overload/short-circuit protection. It operates from 0°C to 80°C ambient temperature with demonstrated MTBF exceeding 550,000 hours at full load and 25°C, making it suitable for information technology equipment, light industrial systems, and non-patient contact medical, dental, and laboratory applications.

Search Keywords: NPS44M

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Artesyn / Advanced Energy
Part No:
NPS44-M
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504406018
COO:
PH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
40

IN STOCK: 0

On Order: 15   can ship 2/22/27

Factory Lead-Time 29 Weeks

Price (USD)

Qty
Unit Price
1
$80.11
5
$53.30
10
$48.78
40
$44.77
80
$44.03
120
$43.75
280 +
$43.65
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
