A-2014-1-4-R by assmann wsw components
Image is representational - see mfr. specs

A-2014-1-4-R

Assmann WSW Components

Conn Modular Jack RCP 6 POS 2.54mm Solder ST Thru-Hole 6 Terminal 1 Port ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

A-2014-1-4-R is a PCB-mounted modular jack designed for 6P6C (6 position, 6 contact) connectivity with a 180° top entry orientation. The connector features a P.B.T. glass-filled insulator rated UL94V-0 for flame retardancy, and phosphor bronze spring wire contacts with gold plating (6µ") over nickel for reliable electrical performance. Key electrical specifications include a maximum rating current of 1.5A, rating voltage of 120V AC, insulation resistance of 500MO minimum, and contact resistance of 20MO maximum. The jack operates over a temperature range of -40°C to +85°C and is rated for a minimum of 500 mating cycles. This RoHS-compliant connector with flange mounting is ideal for telecommunications, networking, and data communication applications requiring reliable modular connections.

Search Keywords: A201414R

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Assmann WSW Components
Part No:
A-2014-1-4-R
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TRAY
Type:
Modular Jack
Body Orientation:
Straight
Mounting:
Through Hole
Pitch:
2.54 mm
Gender:
RCP
Number of Contacts:
6
Maximum Voltage Rating:
120 VAC
Maximum Current Rating:
1.5 A
Operating Temperature:
-40 to 85 °C

IN STOCK: 9,426

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
100
$0.734
300
$0.667
1,000
$0.614
2,500
$0.573
5,000
$0.571
7,500
$0.570
10,000
$0.569
15,000 +
$0.567
