A-DF-09-LL/Z by assmann wsw components

A-DF-09-LL/Z

Assmann WSW Components

Conn D-Subminiature F 9 POS Solder Cup ST Panel Mount 9 Terminal 1 Port ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Assmann WSW Components A-DF-09-LL/Z is a D-Subminiature connector featuring a solder cup termination for easy and reliable connections. This connector is designed with a 9 position configuration, making it suitable for a variety of applications. With a panel mount design, it can be securely fastened to a surface for a stable connection. The connector has 9 terminals and 1 port, ensuring efficient and organized wiring. Whether you need to create a data link, transmit signals, or control devices, the A-DF-09-LL/Z is a reliable choice for your connectivity needs.

Search Keywords: ADF09LLZ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Assmann WSW Components
Part No:
A-DF-09-LL/Z
RoHS:
Yes
HTS:
8544422000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Body Orientation:
Straight
Contact Plating:
N/A
Maximum Voltage Rating:
N/A
Gender:
F
Housing Material:
Polybutylene Terephthalate
Dimension:
N/A
Mounting:
Panel Mount
Contact Material:
Phosphor Bronze
Maximum Current Rating:
3 A

IN STOCK: 7,711

Ships today, if you order in

Minimum Order: 100

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
100
$0.2604
500
$0.2475
3,000
$0.2332
5,000
$0.2291
8,000
$0.2254
25,000
$0.2162
50,000 +
$0.2107
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
Older Equivalent
A-DF09LL-TL-B
A-DF09LL-TL-B
VIEW PRODUCT
