AWP-14-7240-T by assmann wsw components
Image is representational - see mfr. specs

AWP-14-7240-T

Assmann WSW Components

A 14-position IDC socket with a 2.54 x 2.54mm pitch, central polarizing lug, and gold flash contacts. ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AWP-14-7240-T is a 14-position Insulation Displacement Connector (IDC) socket designed for terminating flat ribbon cables. This version is supplied without a strain relief and features a central polarizing lug to ensure correct mating. Key electrical characteristics include a current rating of 1 Amp, an insulation resistance of 1000 MΩ minimum, and a dielectric withstanding voltage of 500 VAC. Constructed with a UL94V-0 rated P.B.T. insulator and gold-flashed contacts, it is designed to operate in temperatures ranging from -55°C to +105°C, making it suitable for a variety of board-to-cable applications in electronic systems.

Search Keywords: AWP147240T

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Assmann WSW Components
Part No:
AWP-14-7240-T
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
144
Package Type:
TRAY
Type:
IDC Connector
Number of Contacts:
14
Pitch:
2.54 mm
Mounting:
Cable Mount
Termination Method:
IDT
Maximum Voltage Rating:
N/A
Maximum Current Rating:
1 A
Dimension:
22.34 x 6.95 x 10.5 mm
Operating Temperature:
-55 to 105 °C

IN STOCK: 1,653

Ships today, if you order in

On Order: 864   can ship 5/25/26
On Order: 3,600   can ship 8/3/26

Minimum Order Quantity: 144

Multiple: 144

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
144
$0.313
288
$0.297
576
$0.282
1,152
$0.268
36,000
$0.254
72,000 +
$0.243
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
