83006-GRY-100 by belden
Image is representational - see manufacturer specifications
Belden Authorized Distributor

83006-GRY-100

Hook-up Wire 22AWG 30.48m 1.27mm Silver Coated Copper 600VAC ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 83006-GRY-100 is a single-conductor hook-up/lead wire featuring stranded silver-plated copper (SPC) with extruded TFE Teflon insulation, compliant with UL AWM Style 1213 specifications. The wire has an AWG 22 gauge with 19x34 stranding configuration and a TFE insulation wall thickness of 0.010 inches, providing an overall nominal diameter of 0.050 inches. It is rated for 105°C continuous operation under UL standards and meets MIL-W-16878/4 specifications with a 600V, 200°C MIL rating, making it suitable for high-temperature applications. The wire is RoHS compliant, CE marked, and passes UL VVV-1 flame testing, making it ideal for aerospace, industrial instrumentation, and high-reliability electronic assemblies where temperature resistance and signal integrity are critical.

Search Keywords: 83006GRY100

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Belden
Part No:
83006-GRY-100
Alias/AKA:
83006-GRY-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Color:
Gray
Jacket Material:
Tetrafluoroethylene
Packaging:
N/A
Maximum Current Rating:
N/A
Size:
22 AWG
Bunch Stranding:
19x34
Family:
83006
Maximum Voltage Rating:
600 V
Cable Diameter:
1.27 mm
Operating Temperature:
-70 to 200 °C
Shield Type:
N/A
Cable Length:
30 m
Conductor Material:
Silver Plated Copper
Type:
Hook-up Wire
Impedance:
N/A

IN STOCK: 4

Ships today, if you order in

Manufacturer Stock: 100   can ship 10/26/26

Factory Lead-Time 3 Weeks can ship 11/3/26

Price (USD)

Qty
Unit Price
1
$152.00
5
$147.77
10
$145.75
20
$145.38
50
$140.00
100 +
$136.40
Log in for special pricing

Tools/3D Models

Product Guides
