22AR20KLFTR by bi technologies/tt electronics
Image is representational - see mfr. specs

22AR20KLFTR

BI Technologies/TT Electronics

The 22AR20KLFTR is a 20 kOhm, single-turn, surface-mount cermet trimming potentiometer in a 3 mm square package. ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 22AR20KLFTR is a top-adjustment, single-turn cermet trimming potentiometer designed for surface-mount applications. It provides a resistance of 20 kOhms with a standard tolerance of ±20% and has a power rating of 0.125 Watts at 70°C. Key features include a temperature coefficient of ±100 ppm/°C and a robust seal, allowing it to operate reliably across a wide temperature range from -55°C to +125°C. Its compact 3 mm square package makes it ideal for high-density circuit boards requiring precise calibration and tuning.

Search Keywords: 22AR20KLFTR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
BI Technologies/TT Electronics
Part No:
22AR20KLFTR
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
TW
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
1000
Package Type:
Reel
Mounting:
Surface Mount
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
J-Hook
Power Rating:
0.125 (1/8) W
Resistance Value:
20 KOhm
Tolerance:
20 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
3.2 x 3.51 x 2.21 mm
Operating Temperature:
-55 to 125 °C

IN STOCK: 2,410

Ships today, if you order in

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 83 Weeks

Price (USD)

Qty
Unit Price
1,000
$1.24
3,000
$1.19
5,000
$1.10
8,000
$1.09
10,000
$1.07
15,000 +
$1.06
Reel Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
