23AR10KLFTR by bi technologies/tt electronics
Image is representational - see manufacturer specifications
BI Technologies/TT Electronics Authorized Distributor

23AR10KLFTR

Res Cermet Trimmer 10K Ohm 20% 0.25W(1/4W) 1(Elec)/1(Mech)Turns 2.6mm (5 X 5.2 X 2.8mm) J-Hook SMD T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
Reel Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 23AR10KLFTR is a 4mm square sealed single-turn surface mount cermet trimming potentiometer designed for precision resistance adjustment in compact applications. It features a 10kO nominal resistance value with ±20% tolerance, a maximum input voltage of 200 Vdc or rms, and a power rating of 0.25 watts at 70°C. The device offers essentially infinite resolution with an actual electrical travel of 210°, dielectric strength of 500 Vrms, and insulation resistance of 100 megohms minimum. Environmental sealing with 85°C Fluorinert ensures no leaks, and the unit operates reliably across a temperature range of -55°C to +125°C with a temperature coefficient of ±100 ppm/°C. This potentiometer is ideal for circuit calibration, signal conditioning, and precision tuning applications where space constraints and environmental protection are critical requirements.

Search Keywords: 23AR10KLFTR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
BI Technologies/TT Electronics
Part No:
23AR10KLFTR
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
TW
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Reel
Mounting:
Surface Mount
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
J-Hook
Power Rating:
0.25 (1/4) W
Resistance Value:
10 KOhm
Tolerance:
20 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
5 x 5 x 2.54 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 1,000

Can Ship immediately

Minimum Order Quantity: 500

Multiple: 500

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
500
$0.797
1,000
$0.764
2,500
$0.740
5,000
$0.705
7,500
$0.696
10,000
$0.689
15,000
$0.686
25,000 +
$0.683
Reel Package
