7286R100L.25

Res Wirewound POT 100 Ohm 5% 2W 10(Elec)/10(Mech)Turns 6.35mm (39.67 X 22.23 X 26.99mm) Turret Panel Mount Clamshell ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 7286R100L.25 is a Model 7280 Series precision potentiometer featuring a 10-turn wirewound design with a 1/4" shaft and 3/8" bushing mount configuration. It offers a 100 ohm resistance value with ±5% standard tolerance and ±0.25% independent linearity, delivering high accuracy for precision measurement and control. The device is lead-free and RoHS 2 compliant, with a 7/8" diameter housing and operates across a wide temperature range from -40°C to +125°C (dynamic) and -55°C to +125°C (static). It withstands 100 G shock (6 ms saw-tooth), 15 G vibration (10–2000 Hz), and 1 million shaft revolutions plus 900 hours at 2.0 watts and 70°C with maximum 5% resistance change. Common applications include pedal position sensing, joystick controls, valve control, wind vane measurement, panel controls, test and measurement equipment, and medical device positioning.

Search Keywords: 7286R100L25

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
BI Technologies/TT Electronics
Part No:
7286R100L.25
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533310000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Mounting:
Panel Mount
Number of Turns:
10(Elec),10(Mech) Tur ns
Termination Style:
Solder
Power Rating:
2 W
Resistance Value:
100 Ohm
Tolerance:
5 %
Temperature Coefficient:
±20 ppm/°C
Dimension:
39.67 x 22.23 x 26.99 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 0

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$60.77
10
$33.99
30
$30.55
50
$28.44
100
$26.96
250
$25.10
500 +
$24.98
