72PR200KLF by bi technologies/tt electronics
Image is representational - see mfr. specs

72PR200KLF

BI Technologies/TT Electronics

Res Cermet Trimmer 200K Ohm 10% 0.5W(1/2W) 1(Elec)/1(Mech)Turn (9.53 X 9.53 X 4.75mm) Pin Thru-Hole Box ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 72PR200KLF is a single-turn trimmer potentiometer from BI Technologies' Model 72 series, featuring a 3/8" square cermet construction designed for precision resistance adjustment. It offers a standard resistance range of 10 ohms to 2 megohms with ±10% tolerance (±20% for values below 100 ohms), and supports a maximum input voltage of 200 Vdc or rms with a power rating of 0.5 watts at 85°C. The device provides an electrical travel of 244° with essentially infinite resolution, maximum end resistance of 2 ohms, and dielectric strength of 900 Vrms, ensuring reliable performance in demanding applications. With an operating temperature range of -55°C to +125°C, low temperature coefficient of ±100 ppm/°C, and robust mechanical design with solid stops and 200-cycle rotational life, the 72PR200KLF is well-suited for instrumentation, calibration circuits, and precision electronic equipment requiring stable, adjustable resistance.

Search Keywords: 72PR200KLF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
BI Technologies/TT Electronics
Part No:
72PR200KLF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Box
Mounting:
Through Hole
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
200 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
9.53 x 9.53 x 4.75 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 1,299

Ships today, if you order in

MOQ for In Stock Qty: 100

MOQ for out of Stock Qty: 300

Multiple: 100

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
100
$1.363
300
$1.274
600
$1.234
900
$1.222
1,200 +
$1.171
Suppliers Standard Package
