8143R10KL.25 by bi technologies/tt electronics
Image is representational - see manufacturer specifications
BI Technologies/TT Electronics Authorized Distributor

8143R10KL.25

The 8143R10KL.25 is a 10 kOhm, 10-turn, servo-mount precision hybrid potentiometer with ±0.25% independent linearity. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 8143R10KL.25 is a servo-mount, 10-turn precision potentiometer from the 8140 hybrid series. It provides a resistance of 10 kOhms with a standard tolerance of ±10% and an independent linearity of ±0.25%. This component is rated for 2.0 Watts at 70°C, has a nominal electrical travel of 3600°, and features a 1/8-inch shaft with ball bearings. Designed for reliability, it operates over a dynamic temperature range of -40°C to +125°C. Its precision and servo-mount configuration make it ideal for use in control systems, instrumentation, and industrial equipment requiring accurate rotational feedback.

Search Keywords: 8143R10KL25

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
BI Technologies/TT Electronics
Part No:
8143R10KL.25
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533310000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Mounting:
Panel Mount
Number of Turns:
10(Elec),10(Mech) Turns
Termination Style:
Turret
Power Rating:
2 W
Resistance Value:
10 KOhm
Tolerance:
10 %
Temperature Coefficient:
±50 ppm/°C
Dimension:
31.75 x 23.4 x 27.58 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 15

Ships today, if you order in

MOQ for out of Stock Qty: 5

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$87.07
5
$86.20
10
$71.54
15
$71.19
20 +
$64.26
Supplier's Standard Package
Log in for special pricing
