P260S-D1AS3CB5K by bi technologies/tt electronics

P260S-D1AS3CB5K

BI Technologies/TT Electronics

Res Conductive Plastic POT 5K Ohm 10% 0.5W(1/2W) 1(Elec)/1(Mech)Turns 3.2mm (38.8 X 13.3 X 12.7mm) Pin Panel Mount/Through Hole Box/Tray ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

P260S-D1AS3CB5K is a 12.7mm (1/2") square rotary panel potentiometer with an integrated rotary switch module, featuring side adjust configuration with PCB leads. It incorporates a metal shaft and bushing construction with sealed/dust proof design and offers a 1,000,000 cycle life rating. The potentiometer supports resistance ranges from 500O to 1MO (for "B" taper) or 2KO to 1MO (for other tapers) with ±10% standard resistance tolerance, and can accommodate up to 5 gangs with the rotary switch. This component meets MIL-PRF-94 requirements and is RoHS compliant, making it ideal for professional audio applications including electric guitars, amplifiers, mixers, drum machines, and synthesizers.

Search Keywords: P260SD1AS3CB5K

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
BI Technologies/TT Electronics
Part No:
P260S-D1AS3CB5K
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
840
Package Type:
Tray
Mounting:
Panel Mount/Through Hole11434
Number of Turns:
1(Elec),1(Mech) Tur ns
Termination Style:
Pin11449
Power Rating:
0.5 (1/2) W
Resistance Value:
5 KOhm
Tolerance:
1011450%
Temperature Coefficient:
N/A
Dimension:
38.8 x 13.3 x 12.711440mm
Operating Temperature:
-55 to 125 °C
Switch Option:
Yes11446
Number of Elements:
111435

IN STOCK: 1,635

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 420

Factory Lead-Time 32 Weeks

Price (USD)

Qty
Unit Price
5
$13.83
100
$8.93
250
$8.56
420
$8.48
840
$8.39
1,260
$8.31
1,680 +
$8.23
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
