09-9748-71-03 by binder-usa
Image is representational - see manufacturer specifications
Binder-USA Authorized Distributor

09-9748-71-03

Snap-In IP40 Female cable connector, Contacts: 3, 3.5-5.0mm, unshielded, solder, IP40 ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 09-9748-71-03 is a subminiature snap-in female cable connector from the series 719, designed for secure and reliable electrical connections in industrial control and plant engineering applications. It features 3 contacts with a cable outlet range of 3.5–5.0 mm, unshielded construction, and solder termination for robust wire attachment. The connector operates at a rated voltage of 60 V with a rated current of 3.0 A, an insulation resistance of =10¹° O, and withstands a rated impulse voltage of 800 V, making it suitable for demanding electrical environments. The housing and contact body are constructed from polyamide (PA) with bronze (CuSn) contacts plated in gold (Au), ensuring durability and corrosion resistance. With an IP40 degree of protection, mechanical operation rated for over 100 mating cycles, and a temperature range of -25 °C to 70 °C, this connector is ideal for applications requiring frequent connection/disconnection cycles in control systems, electrical equipment, and industrial automation.

Search Keywords: 0997487103

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Binder-USA
Part No:
09-9748-71-03
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85369010
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1

IN STOCK: 76

Can Ship immediately

Manufacturer Stock: 260   can ship 10/9/26

Minimum Order Quantity: 5

Factory Lead-Time 7 Weeks can ship 11/12/26

Price (USD)

Qty
Unit Price
5
$6.40
25
$5.87
100
$5.42
250
$5.12
500
$4.89
1,000
$4.67
2,500
$4.37
5,000 +
$4.33
Log in for special pricing Click for Quote Price Match Request
