Image is representational - see manufacturer specifications
Binder-USA Authorized Distributor

99-0430-12-04

M12-A Female cable connector, Contacts: 4, 6.0-8.0mm, unshielded, screw clamp, IP67, UL ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 99-0430-12-04 is an M12 female cable connector designed for industrial automation, sensors, and actuators in the series 713 product line. It features 4 contacts with a cable outlet diameter of 6.0–8.0 mm, screw clamp termination, and an unshielded design compliant with DIN EN 61076-2-101. The connector is rated for 250 V with a rated impulse voltage of 2500 V and a maximum current of 4.0 A per contact, with insulation resistance exceeding 108 O. It operates across a temperature range of -40 °C to +85 °C and is rated for more than 50 mating cycles, providing robust performance in harsh industrial environments. The connector is IP67-rated for dust and water protection, UL 2238 certified, and suitable for plant engineering, control systems, and electrical equipment construction applications.

Search Keywords: 9904301204

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Binder-USA
Part No:
99-0430-12-04
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85369010
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Body Orientation:
Straight

IN STOCK: 0

Manufacturer Stock: 963   can ship 11/16/26

Minimum Order Quantity: 5

Factory Lead-Time 7 Weeks can ship 12/21/26

Price (USD)

Qty
Unit Price
5
$22.27
25
$19.01
50
$17.53
100
$16.51
250
$15.66
500
$15.61
1,000 +
$15.57
Log in for special pricing
