99-1487-822-08 by binder-usa
Image is representational - see mfr. specs

99-1487-822-08

Binder-USA

M12-A Male angled connector, Contacts: 8, 6.0-8.0mm, shieldable, screw clamp, IP67 ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 99-1487-822-08 is an M12 male angled connector designed for industrial automation, sensors, and actuators in the series 713 product line. It features 8 contacts with a cable outlet diameter of 6.0–8.0 mm, screw clamp termination, and IP67 degree of protection, complying with DIN EN 61076-2-101 and UL 2238 standards. The connector is shieldable with a shielding ring for EMC compliance and operates reliably across a temperature range of -40°C to +85°C with a rated voltage of 30 V and rated current of 2.0 A. The housing is constructed from zinc die-cast nickel-plated material with brass contacts plated in gold, ensuring durability and corrosion resistance. This connector is ideal for plant engineering, control systems, and electrical equipment construction where robust, sealed connections are required in harsh industrial environments.

Search Keywords: 99148782208

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Binder-USA
Part No:
99-1487-822-08
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85369010
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Body Orientation:
Right Angle3435

IN STOCK: 24

Can Ship immediately

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
1
$38.09
5
$33.99
10
$33.91
25
$32.02
50
$30.26
100
$30.19
250 +
$29.07
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
