2027-07-BLF by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

2027-07-BLF

Gas Discharge Tubes 75VDC 10KADC 10AAC 1pF Axial Thru-Hole ...

View Datasheet Ask the Datasheet
RoHS Compliant
BULK Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 2027-07-BLF is a 2-pole gas discharge tube designed for overvoltage and surge protection across telecommunications, industrial, commercial, consumer, and automotive electronics. It features an 8 mm diameter and 6 mm length with a DC sparkover voltage of 75 V (±20%) at 100 V/s and impulse sparkover ratings of 300 V at 100 V/µs and 500 V at 1000 V/µs. The device offers high surge current capability with ratings up to 25,000 A (8/20 µs) for single operation and maintains stable breakdown characteristics throughout its operational life. With insulation resistance exceeding 10^10 O at 50 V, glow voltage greater than 70 V at 10 mA, and operating temperature range of -55°C to +125°C, this RoHS-compliant component provides reliable protection in demanding environments. The tube is UL recognized and suitable for custom configurations, making it ideal for protecting sensitive circuits from transient overvoltages in network and communication systems.

Search Keywords: 202707BLF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
2027-07-BLF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BULK
Maximum Impulse Sparkover Voltage@100V/s:
300 V
Maximum Impulse Sparkover Voltage@1KV/s:
500 V
Typical DC Sparkover Voltage@100V/s:
75 V
Number of Electrodes:
2
Packaging:
Bulk
Failsafe Protection:
No
Typical Impulse Discharge Current @ 8/20us @ 10Times:
10 kA
DC Sparkover Voltage Tolerance:
±20 %

IN STOCK: 11,000

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
100
$1.019
300
$0.958
500
$0.902
1,000
$0.824
2,500
$0.822
5,000
$0.680
7,500
$0.678
10,000 +
$0.677
