3005P-1-103 by bourns
Image is representational - see mfr. specs

3005P-1-103

Bourns

Res Wirewound Trimmer 10K Ohm 10% 1W 20(Elec)Turn 2.54mm (20.55 X 4.06 X 7.87mm) Pin Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3005P-1-103 is a 3/4" rectangular Trimpol® trimming potentiometer designed for precision adjustment in industrial applications. This sealed multiturn wirewound device features a 10,000 ohm (10K) resistance with ±10% tolerance, 20 turns of adjustment travel, and a nominal resolution of 0.3%, providing fine-tuning capability for circuit calibration. The potentiometer is sealed to prevent contamination from fluxing, soldering, and cleaning processes, with an insulation resistance of 100 megohms at 500 VDC and dielectric strength of 1,000 VAC at sea level. Operating across a wide temperature range of -65°C to +125°C with a temperature coefficient of ±50 ppm/°C, it delivers 1 watt power rating at 70°C and maintains stability through 200 rotational cycles with 4% maximum resistance change. The device is ideal for test equipment, instrumentation, and industrial control systems requiring reliable, sealed adjustment mechanisms.

Search Keywords: 3005P1103

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3005P-1-103
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533310000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
20(Elec) Tur ns
Termination Style:
Pin
Power Rating:
1 W
Resistance Value:
10 KOhm
Tolerance:
10 %
Temperature Coefficient:
±50 ppm/°C
Dimension:
20.55 x 4.06 x 7.87 mm
Operating Temperature:
-65 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 42

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
5
$13.75
10
$13.42
25
$13.21
50
$13.03
100
$12.60
250
$12.43
500 +
$12.29
