3006P-1-502 by bourns

3006P-1-502

Bourns

Res Cermet Trimmer 5K Ohm 10% 0.75W(3/4W) 15(Elec)Turn 2.36mm (20.57 X 4.83 X 6.35mm) Pin Thru-Hole Tube ...

Datasheet
RoHS Non-Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The BOURNS 3006P-1-502 is a precision cermet trimmer designed for applications requiring accurate resistance adjustment. With a resistance value of 5K Ohms and a tolerance of 10%, this trimmer allows for fine tuning of circuits and devices. It has a power rating of 0.75W (3/4W) and features 15 electrical turns for precise adjustments. The trimmer is encapsulated in a compact size measuring 20.57mm x 4.83mm x 6.35mm, making it suitable for various electronic projects. It is a through-hole component, allowing for easy installation on circuit boards using pins. The trimmers are conveniently packaged in tubes for efficient storage and handling.

Search Keywords: 3006P1502

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3006P-1-502
RoHS:
No
HTS:
8533408050
COO:
HU
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
15(Elec) Turns
Termination Style:
Pin
Power Rating:
0.75 (3/4) W
Resistance Value:
5 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
20.57 x 4.83 x 6.35 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No11446
Number of Elements:
111435
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 200

Can Ship immediately

Minimum Order: 100

Multiple: 100

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
100
$2.404
300
$2.205
500
$2.144
1,000
$2.129
2,500
$2.113
5,000
$2.037
7,500
$2.022
10,000 +
$2.006
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
