3057Y-1-203 by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

3057Y-1-203

Res Wirewound Trimmer 20K Ohm 5% 1W 22(Elec)Turn 2.92mm (33.22 X 4.83 X 8mm) Pin Thru-Hole Tube ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 3057Y-1-203 is a Bourns Trimpot® trimming potentiometer designed for precision resistance adjustment in industrial applications. This multiturn wirewound device features a 20 kO standard resistance with ±5% tolerance, 22 turns of adjustment travel, and a nominal resolution of 0.31%, providing fine control over resistance values. The potentiometer operates across a wide temperature range of -55°C to +150°C with a temperature coefficient of ±50 ppm/°C, and delivers 1 watt power rating at 70°C. With an insulation resistance of 1,000 megohms minimum at 500 VDC and dielectric strength of 1,500 VAC at sea level, this sealed component is RoHS compliant and listed on the QPL for MIL-PRF-27208. The 3057Y style features compact dimensions with flexible leads and is ideal for precision instrumentation, signal conditioning, and calibration circuits requiring reliable long-term performance.

Search Keywords: 3057Y1203

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3057Y-1-203
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533310000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
20
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
22(Elec) Turns
Termination Style:
Pin
Power Rating:
1 W
Resistance Value:
20 KOhm
Tolerance:
5 %
Temperature Coefficient:
±50 ppm/°C
Dimension:
33.22 x 4.83 x 8 mm
Operating Temperature:
-55 to 150 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 20

Ships today, if you order in

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$29.21
5
$27.33
20
$25.29
40
$24.56
60
$24.21
100
$22.90
260 +
$22.29
