3059Y-1-503MLF by bourns

3059Y-1-503MLF

Bourns

Res Cermet Trimmer 50K Ohm 10% 1W 22(Elec)Turn 2.54mm (39.7 X 6.76 X 10.31mm) Pin Panel Mount/Through Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The BOURNS part 3059Y-1-503MLF is a reliable and high-quality cermet trimmer designed for precision adjustments in electronic circuits. With a resistance value of 50K Ohm and a tolerance of 10%, this 1W resistor offers excellent accuracy in regulating circuit parameters. Its 22 (Electrical) Turns provide precise and smooth adjustment capabilities. The trimmer is conveniently designed with a 2.54mm pin spacing, allowing for easy panel mounting or through-hole installation. With dimensions of 39.7mm x 6.76mm x 10.31mm, this trimmer is compact and space-saving. Ideal for various applications, this BOURNS trimmer is supplied in a tube packaging for secure handling and storage.

Search Keywords: 3059Y1503MLF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3059Y-1-503MLF
RoHS:
Yes
HTS:
8536308000
COO:
HU
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
TUBE
Mounting:
Panel Mount/Through Hole
Number of Turns:
22(Elec) Turns
Termination Style:
Pin
Power Rating:
1 W
Resistance Value:
50 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
39.7 x 6.76 x 10.31 mm
Operating Temperature:
-55 to 150 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 26

Ships today, if you order in

On Order: 40   can ship 12/8/25

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$36.720
20
$21.064
40
$20.404
100
$19.755
260
$19.663
500
$19.560
1,000 +
$19.333
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
