3260W-1-502 by bourns
Image is representational - see mfr. specs

3260W-1-502

Bourns

Res Wirewound Trimmer 5K Ohm 5% 0.25W(1/4W) 11(Elec)Turns 1.78mm (6.35 X 4.32 X 7.24mm) Pin Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3260W-1-502 is a 1/4" square Trimpot trimming potentiometer manufactured by Bourns, designed for precision adjustment applications in industrial environments. This multiturn wirewound device features a 5,000 ohm resistance value with ±5% tolerance, 0.34% nominal resolution, and an 11-turn adjustment angle for fine control. The potentiometer operates across a wide temperature range of -65°C to +150°C with a temperature coefficient of ±70 ppm/°C, and delivers 0.25 watts at 85°C. It is sealed, RoHS compliant, and listed on the QPL for MIL-R-27208 style RT26, with dielectric strength rated at 600 VAC at sea level and 1,000 megohms minimum insulation resistance. The device is ideal for circuit trimming, calibration, and processing applications where reliable, repeatable adjustment and environmental durability are required.

Search Keywords: 3260W1502

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3260W-1-502
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533310000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
11(Elec) Turns
Termination Style:
Pin
Power Rating:
0.25 (1/4) W
Resistance Value:
5 KOhm
Tolerance:
5 %
Temperature Coefficient:
±70 ppm/°C
Dimension:
6.35 x 4.32 x 7.24 mm
Operating Temperature:
-65 to 150 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 108

Can Ship immediately

MOQ for out of Stock Qty: 13

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
1
$39.21
5
$39.12
10
$39.02
13
$38.92
25
$30.36
38
$27.96
50 +
$27.41
Suppliers Standard Package
