3269P-1-104GLF by bourns
Image is representational - see mfr. specs

3269P-1-104GLF

Bourns

Res Cermet Trimmer 100K Ohm 10% 0.25W(1/4W) 12(Elec)Turns 1.78mm (6.35 X 8.39 X 5.21mm) Gull Wing SMD T/R ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3269P-1-104GLF is a 1/4" square SMD Trimpot trimming potentiometer manufactured by Bourns with a 100 kO resistance value and infinite resolution cermet element. It features stable performance with ±10% resistance tolerance, adjustability of ±0.02% in voltage divider mode and ±0.05% in rheostat mode, and an effective travel of 12 turns nominal. The device operates over a temperature range of -65°C to +150°C with a power rating of 0.25 watts at 85°C, and includes solderable pins with a maximum adjustment torque of 2.5 oz-in. This trimmer is ideal for precision circuit calibration and tuning applications in consumer electronics, instrumentation, and industrial equipment where compact surface-mount integration and reliable performance are required.

Search Keywords: 3269P1104GLF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3269P-1-104GLF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
750
Package Type:
REEL
Mounting:
Surface Mount
Number of Turns:
12(Elec) Turns
Termination Style:
Gull Wing
Power Rating:
0.25 (1/4) W
Resistance Value:
100 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
6.35 x 8.39 x 5.21 mm
Operating Temperature:
-65 to 150 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 380

Can Ship immediately

Minimum Order Quantity: 100

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
100
$2.03
250
$1.96
750
$1.90
1,500
$1.88
3,000
$1.86
5,250
$1.84
7,500
$1.83
10,500 +
$1.82
Reel Package
