3296X-1-202LF by bourns
Image is representational - see mfr. specs

3296X-1-202LF

Bourns

Res Cermet Trimmer 2K Ohm 10% 0.5W(1/2W) 25(Elec)Turn 2.19mm (11.05 X 4.83 X 10.03mm) Pin Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3296X-1-202LF is a 3/8" square Trimpot® trimming potentiometer manufactured by Bourns, designed for precision resistance adjustment in industrial applications. This multiturn cermet potentiometer features a 2 kO nominal resistance with ±10% tolerance, infinite resolution, and a sealed chevron design for environmental protection. It offers exceptional adjustability with voltage accuracy of ±0.01% and resistance accuracy of ±0.05%, along with an effective travel of 25 turns nominal and a wiper position at 50% (±10%). The device operates reliably across a temperature range of -55°C to +125°C with a temperature coefficient of ±100 ppm/°C, and is rated for 0.5 watts at 70°C. The 3296X-1-202LF is ideal for instrumentation, signal conditioning, and calibration circuits where precise, stable resistance adjustment is required, and is available in RoHS-compliant tin-plated terminations.

Search Keywords: 3296X1202LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3296X-1-202LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
25(Elec) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
2 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
11.05 x 4.83 x 10.03 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 1,000

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
100
$1.302
300
$1.238
500
$1.175
1,000
$1.166
2,500
$1.145
5,000
$1.031
7,500
$1.029
10,000 +
$1.026
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
