3299X-1-202LF by bourns
Image is representational - see mfr. specs

3299X-1-202LF

Bourns

Res Cermet Trimmer 2K Ohm 10% 0.5W(1/2W) 25(Elec)Turn 2.29mm (11.05 X 6.1 X 10.03mm) Pin Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3299X-1-202LF is a 3/8" square multiturn cermet trimming potentiometer (Trimpot) designed for industrial sealed applications requiring precision resistance adjustment. This model features a 2,000 ohm resistance value with ±10% tolerance, 25 turns of effective travel, and infinite resolution for precise voltage and resistance adjustments (±0.01% voltage adjustability, ±0.05% resistance adjustability). The device operates across a temperature range of -55°C to +125°C with a temperature coefficient of ±100 ppm/°C, and is rated for 0.5 watts at 70°C with a maximum torque of 3.0 oz-in. The 3299X-1-202LF features 100% tin-plated RoHS-compliant terminations, solderable pins, and meets UL 94V-0 flammability standards, making it suitable for precision trimming applications in industrial electronics, instrumentation, and signal processing circuits where reliable long-term performance and environmental compliance are essential.

Search Keywords: 3299X1202LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3299X-1-202LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
25(Elec) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
2 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
11.05 x 6.1 x 10.03 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 400

Ships today, if you order in

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
100
$1.34
300
$1.29
500
$1.28
1,000
$1.25
2,500
$1.23
5,000
$1.22
7,500
$1.21
10,000 +
$1.19
