3299Z-1-203LF by bourns
Image is representational - see mfr. specs

3299Z-1-203LF

Bourns

Res Cermet Trimmer 20K Ohm 10% 0.5W(1/2W) 25(Elec)Turn 2.29mm (11.05 X 6.1 X 10.03mm) Pin Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3299Z-1-203LF is a 3/8" square multiturn cermet trimming potentiometer (Trimpot) designed for industrial applications requiring precision adjustment and sealed operation. This model features a 20 kO resistance value (code 203), ±10% resistance tolerance, and infinite resolution with ±0.05% adjustability. It operates over a temperature range of -55°C to +125°C with a temperature coefficient of ±100 ppm/°C, and delivers 0.5 watts at 70°C and 0 watts at 125°C. The device includes 25 turns of effective travel, 1,000 megohms minimum dielectric strength, and is sealed to MIL-STD-202 humidity standards with U.L. 94V-0 flammability rating. The 3299Z-1-203LF is ideal for circuit calibration, signal conditioning, and precision tuning applications in industrial control systems, instrumentation, and electronic equipment where reliable, sealed adjustment is essential.

Search Keywords: 3299Z1203LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3299Z-1-203LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
25(Elec) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
20 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
11.05 x 6.1 x 10.03 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 200

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
100
$1.71
300
$1.59
500
$1.58
1,000
$1.47
2,500
$1.43
5,000
$1.40
7,500
$1.39
10,000 +
$1.38
