3299Z-1-502LF by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

3299Z-1-502LF

Res Cermet Trimmer 5K Ohm 10% 0.5W(1/2W) 25(Elec)Turn 2.29mm (11.05 X 6.1 X 10.03mm) Pin Thru-Hole Tube ...

View Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 3299Z-1-502LF is a 3/8" square multiturn cermet trimming potentiometer (Trimpot) designed for industrial sealed applications. This device features a resistance value of 5,000 ohms with ±10% tolerance, infinite resolution, and 25 turns of effective travel for precise voltage and resistance adjustments of ±0.01% and ±0.05% respectively. The potentiometer operates across a temperature range of -55°C to +125°C with a temperature coefficient of ±100 ppm/°C, and is rated for 0.5 watts at 70°C and 0 watts at 125°C (maximum 300 volts). It features solderable pins with 100% tin-plated (RoHS compliant) termination, U.L. 94V-0 flammability rating, and includes mechanical stops with a wiper set at 50% of actual travel resistance. The sealed design with standoffs and five popular terminal styles makes it ideal for precision trimming applications in industrial equipment, instrumentation, and signal processing circuits where reliable long-term performance and environmental protection are required.

Search Keywords: 3299Z1502LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3299Z-1-502LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
25(Elec) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
5 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
11.05 x 6.1 x 10.03 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 300

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
100
$1.84
300
$1.74
500
$1.60
1,000
$1.51
2,500
$1.50
5,000
$1.45
7,500
$1.44
10,000 +
$1.43
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
