3306F-1-102 by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

3306F-1-102

Res Cermet Trimmer 1K Ohm 25% 0.2W(1/5W) 1(Elec)/1(Mech)Turns 3.4mm (6.81 X 8.1 X 7.62mm) Pin Thru-Hole Bag ...

View Datasheet Ask the Datasheet
RoHS Compliant
BULK Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 3306F-1-102 is a 6 mm round single-turn Trimpot® trimming potentiometer manufactured by Bourns for industrial and open-frame applications. It features a 1 kO nominal resistance with ±25% standard tolerance, essentially infinite resolution, and a 215° nominal adjustment angle with a maximum mechanical angle of 260° ±20°. The device is rated for 0.2 watts at 70 °C with a maximum voltage of 100 volts, operates across a temperature range of -25 °C to +100 °C with a temperature coefficient of ±250 ppm/°C, and exhibits contact resistance variation of 3% maximum and absolute minimum resistance of 2% maximum. It features cross-slot adjustment options, dust and splash-resistant covers, horizontal and vertical mounting styles, and solderable pin terminals. The 3306F-1-102 is ideal for precision circuit tuning, calibration, and trimming applications in industrial equipment, test instruments, and consumer electronics requiring reliable potentiometric adjustment.

Search Keywords: 3306F1102

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3306F-1-102
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
SG
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2000
Package Type:
BULK
Mounting:
Through Hole
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
Pin
Power Rating:
0.2 (1/5) W
Resistance Value:
1 KOhm
Tolerance:
25 %
Temperature Coefficient:
±250 ppm/°C
Dimension:
6.81 x 8.1 x 7.62 mm
Operating Temperature:
-25 to 100 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 1

Can Ship immediately

Buy all 1 in-stock or the regular minimum order quantity of 100

Stock lot only: 1

Minimum Order Quantity: 100

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$0.5224
100
$0.4749
2,000
$0.3075
4,000
$0.2894
6,000
$0.2887
8,000
$0.2880
26,000
$0.2873
50,000 +
$0.2865
Supplier's Standard Package
