3386S-1-502LF by bourns
Image is representational - see mfr. specs

3386S-1-502LF

Bourns

Res Cermet Trimmer 5K Ohm 10% 0.5W(1/2W) 1(Elec)/1(Mech)Turn 3.15mm (9.53 X 4.83 X 9.53mm) Pin Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

3386S-1-502LF is a 3/8" square Trimpot trimming potentiometer designed for precision resistance adjustment in industrial applications. This single-turn cermet potentiometer features a 5 kO resistance value (resistance code 502), side adjust configuration, and sealed construction for enhanced reliability. Key electrical characteristics include a resistance tolerance of ±10%, power rating of 0.5 watt at 85°C, and an adjustment angle of 280° nominal with infinite resolution. The device operates over a temperature range of -55°C to +125°C with a temperature coefficient of ±100 ppm/°C. The "LF" suffix indicates RoHS compliant 100% tin-plated terminations, making it suitable for lead-free assembly processes in instrumentation, calibration, and circuit tuning applications.

Search Keywords: 3386S1502LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3386S-1-502LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
5 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
9.53 x 4.83 x 9.53 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 449

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
100
$0.927
300
$0.869
500
$0.806
1,000
$0.804
2,500
$0.752
5,000
$0.732
7,500
$0.730
10,000 +
$0.713
