3540S-1-203L by bourns
Image is representational - see mfr. specs

3540S-1-203L

Bourns

Res Wirewound POT 20K Ohm 5% 2W 10(Elec)/10(Mech)Turns 6.34mm (22.23 X 39.67 X 26.99mm) Solder Lug Panel Mount ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

3540S-1-203L is a precision wirewound potentiometer from the Bourns 3540 series, designed for applications requiring accurate and repeatable resistance adjustment. It features a 20,000 O resistance value with ±5% tolerance, 0.014% resolution, and ±0.25% independent linearity over an effective electrical angle of 3600° (+10°, -0°). The bushing mount design includes gold-plated solder lugs for reliable connections, with a power rating of 2 watts and dielectric withstanding voltage of 1,000 VAC minimum at sea level. This RoHS compliant potentiometer is ideal for precision instrumentation, calibration equipment, and industrial control systems where high accuracy and stability are essential.

Search Keywords: 3540S1203L

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3540S-1-203L
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533310000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
TRAY
Mounting:
Panel Mount
Number of Turns:
10(Elec),10(Mech) Tur ns
Termination Style:
Solder Lug
Power Rating:
2 W
Resistance Value:
20 KOhm
Tolerance:
5 %
Temperature Coefficient:
±50 ppm/°C
Dimension:
39.67 x 26.99 x 22.23 mm
Operating Temperature:
-40 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 50

Ships today, if you order in

Minimum Order Quantity: 10

Multiple: 10

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
10
$24.36
30
$23.63
50
$22.62
100
$21.39
250
$20.83
500
$20.30
1,000 +
$20.25
