Image is representational - see manufacturer specifications
Bourns Authorized Distributor

3856A-282-104AL

Res Cermet POT 100K Ohm 10% 2W 1(Elec)/3.75(Mech)Turn 6.35mm (28.55 X 19.05 X 23.55mm) Solder Lug Panel Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

3856A-282-104AL is a 3/4" (19.05 mm) diameter 3-3/4-turn cermet element panel control potentiometer designed for precision adjustment applications. It features a 100 kO resistance value with a linear taper and ±10% tolerance, utilizing a plain 3/8" (9.53 mm) bushing (Type A) and a 7/8" (22.20 mm) long x 1/4" (6.35 mm) diameter slotted shaft. The mechanical angle is 1350° ±50° with a starting and running torque of 0.11 to 2.12 N-cm (0.15 to 3.0 oz.-in.) and a stop strength of 56.5 N-cm (5 lb.-in.). This RoHS compliant potentiometer weighs a maximum of 30 grams and is suitable for panel-mounted control applications requiring fine resolution and wide resistance range adjustment.

Search Keywords: 3856A282104AL

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3856A-282-104AL
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
45
Package Type:
TRAY
Mounting:
Panel Mount
Number of Turns:
1(Elec),3.75(Mech) Turns
Termination Style:
Solder
Power Rating:
2 W
Resistance Value:
100 KOhm
Tolerance:
10 %
Temperature Coefficient:
±150 ppm/°C
Dimension:
28.55 x 19.05 x 23.55 mm
Operating Temperature:
-1 to 125 °C
Switch Option:
No11446
Number of Elements:
111435

IN STOCK: 119

Can Ship immediately

MOQ for out of Stock Qty: 68

Factory Lead-Time 31 Weeks

Price (USD)

Qty
Unit Price
1
$45.93
10
$45.81
25
$45.70
50
$45.59
68
$45.47
135
$24.25
203
$17.03
270 +
$16.69
Log in for special pricing
