4116R-1-122LF by bourns
Image is representational - see mfr. specs

4116R-1-122LF

Bourns

Res Thick Film NET 1.2K Ohm 2% 2.25W A±100ppm/A°C ISOL Molded 16-Pin DIP Pin Thru-Hole ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 4116R-1-122LF is a thick-film molded DIP resistor network from Bourns' 4100R Series, featuring 8 isolated resistors with a nominal resistance of 1200 ohms (code 122). This component operates over a temperature range of -55°C to +125°C with a maximum operating voltage of 100 V and exhibits a temperature coefficient of resistance of ±250 ppm/°C for values above 2.2 MO. The device delivers a power rating of 0.250 watt per resistor at 70°C and maintains superior package integrity with a molded DIP configuration compatible with automatic insertion equipment. The tin-plated (RoHS-compliant) termination meets MIL-STD-202 Method 208 solderability requirements, making it suitable for DRAM applications, R/2R ladder networks, SCSI applications, and other precision circuit implementations requiring reliable resistor networks.

Search Keywords: 4116R1122LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
4116R-1-122LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
TUBE
Case Size:
N/R
Circuit Designator:
ISOL
Number of Resistors:
8
Number of Terminals:
16
Power Rating:
2.25 W
Power Rating per Resistor:
0.25 (1/4) W
Resistance Value:
1.2 KOhm
Tolerance:
2 %
Temperature Coefficient:
±100 ppm/°C
Termination Style:
Pin

IN STOCK: 903

Ships today, if you order in

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
25
$1.358
250
$1.118
500
$1.041
1,000
$1.039
2,500
$0.976
5,000
$0.953
7,500
$0.930
10,000 +
$0.928
Suppliers Standard Package
